SIF Series Ac/Dc High-Precision Current Sensor For Variable Frequency Speed Motor

Send Inquiry

Product Description

Our high-precision current sensors are designed based on advanced fluxgate principle and have excellent performance. Its main features include: • High accuracy and excellent linearity: ensure accurate measurement results. • Low temperature drift and low zero drift: maintain stable performance under various environmental conditions. • Fast response time: respond to current changes in real time to improve system efficiency. • Strong anti-interference ability: effectively resist external electromagnetic interference and ensure data reliability. • High overload capacity: can work stably under extreme conditions. • Small additional inductance and no insertion loss: reduce the impact on the circuit and improve the overall performance.

Model	SIF30G	SIF50G	SIF100G	SIF200G
Electrical Parameters
Measuring range	120%
Range input	0~±30A	0~±50A	0~±100A	0~±200A
Rated measuring output	± mA 30	±50mA	±100mA	±100mA
Power supply voltage	±12V~±15V ±18V~±24V
Current consumption	±30mA (@±15V)
Turns ratio	1:1000	1:1000	1:1000	1:2000
Accurate dynamic performance parameters
Accuracy	≤±0.05%
Linearity	≤±0.01%
Temperature drift	≤±10μA
Response time	≤1μs
Offset current	T=25℃, ≤±5μA
Band width	DC 100kHz
Load resistance	≤100Ω
Isolation withstand voltage	5kV/50Hz/1min×1mA
