Ultra-Precise SIHD-KY2 Series Current Sensor for Efficient Electrical Monitoring

Quick and easy installationHigh precision, high reliabilityLinear output, fast responseVarious output currents and voltagesStrong resistance to external magnetic field interferenceGood stability, no accumulated errorModelSIHD1000KY2SIHD1500KY2SIHD2000KY2Primary rated input currentDC1000A DC1500A DC2......

Send Inquiry

Product Description

Quick and easy installation

High precision, high reliability

Linear output, fast response

Various output currents and voltages

Strong resistance to external magnetic field interference

Good stability, no accumulated error

Model	SIHD1000KY2	SIHD1500KY2	SIHD2000KY2
Primary rated input current	DC1000A	DC1500A	DC2000A
Primary current measurement range	120%
Secondary side rated output	DC0-5V，DC0-10V，4-20mA
Working power supply	±15V~±24V
Current consumption	10＋ISmA
Accuracy	≤1%
Linearity	≤0.5%
Offset voltage	T=25℃，≤±25mV
Temperature drift	≤±0.08%/℃
Response time	Transmission output ≤150ms, tracking output ≤10μs
Load resistance	Voltage output ≥ 2kΩ, current output ≤ 250Ω
Tracking speed	≥50A/μs
Measurement bandwidth	DC~100kHz
Working temperature	-40℃~85℃
Storage temperature	-40℃~90℃
Isolation withstand voltage	2~6kV/50Hz/1min×1mA
Install	Screw fixing Terminal wiring

Current isolation measurement, power supply monitoring, uninterruptible power supply UPS, welding equipment, railway locomotives, communication power supply, industrial automation control, electrochemistry

Ever-Power Technology Co., Ltd. was established in 2010. It is a high-tech enterprise engaged in system research and development, production, sales and service in the fields of high-speed signal processing, electromechanical control, etc. The company is guided by military development, driven by scientific and technological innovation, and supported by talent development. It has been deeply involved in the electronics industry for more than ten years and has a high-quality, high-tech and high-level engineering and technical team. Electricity sensors, transmitters, and mutual inductors are the electricity isolation detection products launched by Ever-Power Technology in recent years in response to market demand and combined with the company's own product structure advantages. After years of continuous improvement and updating of this type of product, several major series and hundreds of specifications have been formed. The products are widely used in communications, instrumentation, metallurgy, railways, navigation, aerospace and other fields and are generally recognized by users.
