MDH80 Dalian Machine Center High Quality Slant Bed Type Cnc Lathe Turning Center with Live Tool

Raydafon Group's MDH80 Dalian Machine Center is a high-quality slant bed type CNC lathe turning center with live tool, perfect for precision machining in manufacturing. Its robust design and advanced technology ensure durability and efficiency, ideal for professionals in metalworking industries. Experience enhanced productivity and reliability with this superior machine.
Send Inquiry
Product Description
MDH80 Dalian Machine Center High Quality Slant Bed Type Cnc Lathe Turning Center with Live Tool
MDH80 Dalian Machine Center High Quality Slant Bed Type Cnc Lathe Turning Center with Live Tool
MDH80 Dalian Machine Center High Quality Slant Bed Type Cnc Lathe Turning Center with Live Tool


TABLE
Worktable size
mm
800*800
Workpiece size range
mm
φ1110*1220
Max load of worktable
kg
1300
X/Y/Z axis travel
mm
1050/900/900



SPINDLE
Spindle speed
r/min
8000(6000/12000 Optional)
Spindle taper

NO.50(7:24)
Spindle drive mode

Motorized spindle
Spindle power
kw
18.5
Spindle maximum torque
nm
24
MOVEMENT
X/Y/Z cutting speed
m/min
20
MOVEMENT
X/Y/Z feeding speed
m/min
54




ATC SYSTEM
Tool magazine capacity

40(60/80/120 Optional)
Tool shank type

BT50-45°
Max. tool weight
kg
25
Max. tool diameter (w/o adjacent tools)
mm
 φ115
Max.tool length
mm
500
Time of tool change (T-T)
s
2

ACCURACY
X/Y/Z axis positioning accuracy
mm
0.01
X/Y/Z axis repeatability accuracy
mm
0.006
CONTROL SYSTEM
Controller

GSK/SIEMENS/FANUC
MDH80 Dalian Machine Center High Quality Slant Bed Type Cnc Lathe Turning Center with Live Tool
MDH80 Dalian Machine Center High Quality Slant Bed Type Cnc Lathe Turning Center with Live Tool
MDH80 Dalian Machine Center High Quality Slant Bed Type Cnc Lathe Turning Center with Live Tool
MDH80 Dalian Machine Center High Quality Slant Bed Type Cnc Lathe Turning Center with Live Tool
MDH80 Dalian Machine Center High Quality Slant Bed Type Cnc Lathe Turning Center with Live Tool
MDH80 Dalian Machine Center High Quality Slant Bed Type Cnc Lathe Turning Center with Live Tool
Hot Tags: Slant Bed CNC Lathe, High Precision Turning Center, Live Tool CNC Machine
