CNC Slant Bed Lathe Machine Model Max Travel Axes Key Motor Training Power Time Technical Parts Sales Video Tool Energy

Discover Raydafon Group's CNC Slant Bed Lathe Machine: Precision engineering with max travel axes, powerful motor, and energy-efficient performance. Ideal for technical parts manufacturing, it boosts productivity with training and sales video support, delivering unmatched accuracy and reliability. Elevate your tool capabilities today!
Send Inquiry
Product Description
CNC Slant Bed Lathe Machine Model Max Travel Axes Key Motor Training Power Time Technical Parts Sales Video Tool Energy
CNC Slant Bed Lathe Machine Model Max Travel Axes Key Motor Training Power Time Technical Parts Sales Video Tool Energy
CNC Slant Bed Lathe Machine Model Max Travel Axes Key Motor Training Power Time Technical Parts Sales Video Tool Energy


TABLE
Worktable size
mm
800*800
Workpiece size range
mm
φ1110*1220
Max load of worktable
kg
1300
X/Y/Z axis travel
mm
1050/900/900



SPINDLE
Spindle speed
r/min
8000(6000/12000 Optional)
Spindle taper

NO.50(7:24)
Spindle drive mode

Motorized spindle
Spindle power
kw
18.5
Spindle maximum torque
nm
24
MOVEMENT
X/Y/Z cutting speed
m/min
20
MOVEMENT
X/Y/Z feeding speed
m/min
54




ATC SYSTEM
Tool magazine capacity

40(60/80/120 Optional)
Tool shank type

BT50-45°
Max. tool weight
kg
25
Max. tool diameter (w/o adjacent tools)
mm
 φ115
Max.tool length
mm
500
Time of tool change (T-T)
s
2

ACCURACY
X/Y/Z axis positioning accuracy
mm
0.01
X/Y/Z axis repeatability accuracy
mm
0.006
CONTROL SYSTEM
Controller

GSK/SIEMENS/FANUC
CNC Slant Bed Lathe Machine Model Max Travel Axes Key Motor Training Power Time Technical Parts Sales Video Tool Energy
CNC Slant Bed Lathe Machine Model Max Travel Axes Key Motor Training Power Time Technical Parts Sales Video Tool Energy
CNC Slant Bed Lathe Machine Model Max Travel Axes Key Motor Training Power Time Technical Parts Sales Video Tool Energy
CNC Slant Bed Lathe Machine Model Max Travel Axes Key Motor Training Power Time Technical Parts Sales Video Tool Energy
Hot Tags: CNC Slant Bed Lathe Machine, High Precision Lathe Supplier, Custom CNC Machine Solutions
