Cycloidal Pin Wheel ReducerCycloidal gear reducer has solid shaft output, hollow shaft output and contract disk hollow shaft output,which can be installed horizontally , vertically. Cycloidal Gearbox is made of high strength quality alloy steel through quenching and possesses high efficiency and lon......

Send Inquiry

Product Description

Cycloidal Pin Wheel Reducer

Cycloidal gear reducer has solid shaft output, hollow shaft output and contract disk hollow shaft output,which can be installed horizontally , vertically. Cycloidal Gearbox is made of high strength quality alloy steel through quenching and possesses high efficiency and long life gear .Othermore,Cycloidal gear reducer can bear large axial and radial load.Features is low in run noise, high in reliability, compact and so on.

Product Application
Cycloid reducer is a cycloid needle teeth meshing planetary transmission principle drive models, is an ideal transmission has many advantages, versatile, and can be both positive and negative operation.
Perfect for the machinery and equipment of following industry:
- Power Plant Equipment
- Metallurgical Industry
- Metal Forming Machinery
- Petrochemical Industry & Mining Machine
- Hoisting Machinery
- Construction Industry
- Environmental Protection Industry
- Cable Industry
- Food Machinery

Product Feature
- Single stage drive with reduction ratio 1:87, high effciency.
- Input shaft and ourput shaft are in the same axis, so it's compact in structure. .
- Cycloid gear with high overlap coefficient, steady the machine and lower the noise.
- The reducer is made by bearing steel, it's has a long sevice life.

Size	X1	X2	X3	X4	X5	X6	X7	X8	X9
Size		B09	B0	B1	B2	B3	B4		B5	B6
Output Torque N.M
Speed Ratio	Input Speed 1500 rpm										1000 rpm
11	26	48.3	141.7	257.6	483.0	708.3	965.9	1787.0	2125.1
17	40	74.6	149.3	398.1	746.4	1094.7	1492.8	2761.8	3284.3
23	27	53.9	202.0	296.2	740.5	1481.8	1481.8	3736.5	3736.5
29	34	67.9	186.7	373.5	933.7	1867.4	1867.4	2546.5	4711.3
35	41	82	225.4	307.4	819.6	1536.7	2253.8	3673.4	5686.5
43	50	100.7	151.0	377.6	755.2	1384.5	1887.9	2768.9	3775.8
59			207.2	380.0	759.9	1381.5	1899.6	2590.4	3799.3
71			166.3	332.5	623.5	1246.9	1662.5	2286.0	4572.0
87				280.1	764.0	1120.5	2037.2	2037.2	7639.5

THICKENING BASE

The box body is made of HT200 material,which is cleaned by professional screening and washing equipment to ensure that the inner cavity of the box body is cleaner without iron filings.

_{REDUCER SHAFT}

New national standard shaft.

Multi-precision machining, through strict dynamic and static balance test procedures, to ensure the reducer running low noise, balance smooth.

PROFESSIONAL AIR TIGHTNRSS TEST

Semi-Automatic PET Bottle Blowing Machine Bottle Making Machine Bottle Moulding Machine
PET Bottle Making Machine is suitable for producing PET plastic containers and bottles in all shapes.

Cycloid wheel

The cycloid wheel hardened bearing steel,

high strength, long service life of the rolling friction contact parts adopt.

PRODUCT CHARACTERISTICS
High Speed Ratio and High Efficiency

Single-stage transmission can achieve a deceleration ratio of 1:87, and the efficiency is over 90%. If multi-stage transmission, the deceleration ratio is larger.

Compact structure and small volume

Because the planetary transmission principle is adopted, the input shaft and the output shaft are on the same axis, so the structure is compact and the volume is small.

Smooth operation and low noise

Cycloidal pin teeth have many meshing teeth, large overlap coefficient and smooth mechanism, which limits vibration and noise to a minimum.

Reliable use and long service life

Because the main parts are bearing steel, high strength is obtained by quenching treatment (HRC58-62), and rolling friction is used in some transmission contacts, which is durable and has long service life.

CLICK HERE FOR MORE DISCOUNT!

BWD Series Cycloidal Gear Speed Reducer with AC Motor

BWD0 BWD1 BWD2 BWD3 BWD4 BWD5 BWD6 BWD7
XWD0 XWD1 XWD2 XWD3..........
BLD0 BLD1 BLD3 BLD4 BLD5 BLD6 BLD7
XLD0 XLD1 XLD2 XLD3......

WITH OR WITHOUT MOTOR DEPENDS ON YOUR REQUIREMENT

Quick Details:

X,B series cycloidal reducer motor planetary transmission principle is an application ,using cycloid meshing , advanced design, novel structure of the reduction gear. This gear has been replaced in most cases two , three ordinary cylindrical gear reducer and cylindrical worm reducer, in the , aerospace, metallurgy, mining , petroleum, chemicals, shipbuilding, light industry, food, textile, printing and dyeing , pharmaceutical, rubber, plastics, and lifting transport and other aspects of an increasingly wide range of applications.

Advantages

High speed ratio and efficiency
Single stage transmission can reach to 1:87 of speed-down ratio and the efficiency is more than 90%. If use multi-speed drive the speed-down ratio is bigger.
Compact
Being adapted epicyclic transmission principle, the input and output shaft are at same axis center, it is compact.
Smooth and stable run and low noise
The cycloidal pinwheel has more meshed teeth, the overlapping coefficient id big and the machine part is stable, the vibration and noise is limited at the minimum content. Reliable in operation and long life
Because the main parts are made of bearing steel through quenching treatment(HRC58-62), it got high strength. Meanwhile the transmission contact of part adapts rolling friction, so it is durable and long life.Because of reasonable in design, convenient in maintenance, easy to disassemble and assemble, the minimum amount of part and simple lubrication, so it is trusted by customers deeply.

Type	Cycloidal-Pin Gear Speed Reducer
Input Speed	1400-1500rmp
Output Speed	14-280rpm
Certification	ISO9001 CE 3C Ex
Power	0.18-132KW

For more models, please contact us!

Q: Are you trading company or manufacturer ?A: Our group consists in 3 factories and 2 abroad sales corporations.Q: Do you provide samples ? is it free or extra ?A: Yes, we could offer the sample for free charge but do not pay the cost of freight.Q: How long is your delivery time ? What is your terms of payment ?A: Generally it is 40-45 days. The time may vary depending on the product and the level of customization. For standard products, the payment is: 30% T/T in advance ,balance before shippment.Q: What is the exact MOQ or price for your product ?A: As an OEM company, we can provide and adapt our products to a wide range of needs.Thus, MOQ and price may greatly vary with size, material and further specifications; For instance, costly products or standard products will usually have a lower MOQ. Please contact us with all relevant details to get the most accurate quotation.If you have another question, please feel free to contact us.
