Multifunctional CNC Horizontal Machining Center Horizontal Milling Machine CNC Milling Machine for Metal

Raydafon Group's Multifunctional CNC Horizontal Machining Center excels in precision metal milling with advanced CNC technology for superior accuracy and efficiency, ideal for manufacturing industries, offering reliable performance and unmatched productivity.
Send Inquiry
Product Description
Multifunctional CNC Horizontal Machining Center Horizontal Milling Machine CNC Milling Machine For Metal
Multifunctional CNC Horizontal Machining Center Horizontal Milling Machine CNC Milling Machine for Metal
Multifunctional CNC Horizontal Machining Center Horizontal Milling Machine CNC Milling Machine for Metal
Multifunctional CNC Horizontal Machining Center Horizontal Milling Machine CNC Milling Machine for Metal


TABLE
Worktable size
mm
800*800
Workpiece size range
mm
φ1110*1220
Max load of worktable
kg
1300
X/Y/Z axis travel
mm
1050/900/900



SPINDLE
Spindle speed
r/min
8000(6000/12000 Optional)
Spindle taper

NO.50(7:24)
Spindle drive mode

Motorized spindle
Spindle power
kw
18.5
Spindle maximum torque
nm
24
MOVEMENT
X/Y/Z cutting speed
m/min
20
MOVEMENT
X/Y/Z feeding speed
m/min
54




ATC SYSTEM
Tool magazine capacity

40(60/80/120 Optional)
Tool shank type

BT50-45°
Max. tool weight
kg
25
Max. tool diameter (w/o adjacent tools)
mm
 φ115
Max.tool length
mm
500
Time of tool change (T-T)
s
2

ACCURACY
X/Y/Z axis positioning accuracy
mm
0.01
X/Y/Z axis repeatability accuracy
mm
0.006
CONTROL SYSTEM
Controller

GSK/SIEMENS/FANUC
Multifunctional CNC Horizontal Machining Center Horizontal Milling Machine CNC Milling Machine for Metal
