Large SP1330 Double Column Machining Center CNC Lathe Cnc Machine With Semi-closed Loop Control

SP1300 Double Column Machining CenterThis series of column beam fixed double column machining centers adopts the international dynamic stiffness design concept to optimize the design of moving components based on the high stiffness, structural symmetry, and high stability of traditional double colum......

Send Inquiry

Product Description

SP1300 Double Column Machining Center

This series of column beam fixed double column machining centers adopts the international dynamic stiffness design concept to optimize the design of moving components based on the high stiffness, structural symmetry, and high stability of traditional double column machining. This series of large CNC machine tools has the characteristics of high torque and fast feedback, which can meet the needs of mechanical processing fields such as automobiles, molds, aviation, and industry. This series of machine tools mainly consists of components such as base, workbench, column, crossbeam, saddle, hydraulic system, lubrication system, cooling and filtering system, chip cutting device, CNC system, etc.Here are its key advantages and applications:1. High Precision Machining: The SP1300 provides exceptional precision and accuracy in machining operations. It is ideal for applications that require tight tolerances and precise positioning, such as aerospace components, automotive parts, and mold making. 2. Large Workpiece Machining: With its spacious working area, the SP1300 accommodates large workpieces. It is suitable for industries that deal with oversized components, such as heavy machinery, construction equipment, and marine applications. 3. Heavy-Duty Machining: The robust double column design of the SP1300 ensures stability and rigidity during heavy-duty machining tasks. It can handle tough materials like steel, cast iron, and titanium, making it well-suited for industries like energy, oil and gas, and heavy equipment manufacturing. 4. Multi-Axis Machining: The SP1300 supports multi-axis machining, including 3-axis, 4-axis, and 5-axis operations. This versatility allows for complex machining tasks, such as multi-sided milling, contouring, and simultaneous machining of multiple features. 5. High-Speed Machining: Equipped with a high-speed spindle and advanced control systems, the SP1300 enables high-speed machining operations. It is beneficial for industries that require efficient material removal rates, such as automotive, aerospace, and electronics manufacturing. 6. Efficient Tool Changing: The SP1300 features an automatic tool changer, allowing for quick and seamless tool changes. This enhances productivity and reduces downtime, making it suitable for industries that require frequent tool changes, such as job shops and high-volume production facilities. 7. Versatile Applications: The SP1300 finds applications in diverse industries, including aerospace, automotive, energy, mold and die, general machining, and more. It can handle various materials, such as metals, alloys, composites, and plastics, catering to a wide range of manufacturing needs. 8. Reliability and Durability: Built with high-quality components and robust construction, the SP1300 offers reliable performance and long-term durability. It can withstand demanding production environments, ensuring consistent results and minimizing maintenance requirements.

Model		SP1016	SP1020	SP1325	SP1330	SP1525
Travel and processing range
X-axis travel	mm	1650	2050	2600	3100	2600
Y-axis travel	mm	1200	1200	1400	1400	1400
Z-axis travel	mm	600	600	160-960	160-960	160-960
Distance from spindle nose to worktable	mm	160-760	160-760	2	1	2
Distance from ground to workbench surface	mm	765	765	775	775	775
Distance between two columns	mm	1250	1250	1400	1400	1650
Staging
Workbench area (X-axis direction)	mm	1600	2000	2500	3000	2500
Workbench area (Y-axis direction)	mm	1000	1000	1300	1300	1500
Maximum load of workbench	kg	3000	3500	4000	5000	4000
Size and number of T-shaped grooves on the surface of the workbench (width * number of slots * spacing)	mm	227125	227125	227160	227160	229160
Feed System
Rapid displacement (X-axis)	mm/min	20000	20000	10000	10000	10000
Rapid displacement (Y-axis)	mm/min	20000	20000	10000	10000	10000
Rapid displacement (Z-axis)	mm/min	12000	12000	10000	10000	10000
Main spindle
Main spindle power (continuous/30 minutes)	kw	15/18.5	15/18.5	15/18.5	15/18.5	15/18.5
Maximum speed (vertical shaft)	rpm	7000	7000	6000	6000	6000
Spindle hole thrust	Nm	71.5	71.5	143	143	143
Spindle taper hole	#	50	50	50	50	50
Spindle cutting force	kgf	1800±10%	1800±10%	1800±10%	1800±10%	1800±10%
Main spindle bearing size	mm	7016	7016	7018	7018	7018

Direct drive spindle, C.T.S, Gear box,Increase column height, Upgrade tool magazine to 30T,40T,60T.

Equipped with oil chiller,cycle cooling
source for spindle unit and motor cabinet.

Hydraulic station,power source for balancing cylinder and spindle tool clamping and unclamping.

Lubrication station is controlled by
CNC system which can test and alarm
automatically.

Level test of cool liquid

Tool magazine has adjusting device

Spindle unit(Hydraulic tool clamping and unclamping)

CNC machines

*CNC worm grinding machine *CNC forming gear grinding machine *CNC rolling cutter shovel grinding machine *CNC cutting edge grinder *CNC grinding wheel repair machine *CNC shovel tooth lathe *Fully CNC high-speed gear hobbing machine

Processing tools

*Measuring instruments*Production equipment*Gear hob*Insert gear hob*Gear hob*Worm gear hob*Involute spline hob*Triangular spline hob rectangular spline hob*Sprocket roller cutter*Circular arc gear hob*Synchronous belt roller cutter

Ever-power is a leading manufacturer and industrial service provider of CNC machine tools and intelligent equipment in the industry. It was established through strategic cooperation between Sichuan De'en Precision Technology Co., Ltd. and Jiangsu Youzhixiang Intelligent Manufacturing Co., Ltd. It has established two CNC machine tool production bases in Jiashan, Zhejiang and Pingshan, Yibin, Sichuan, with complete casting production lines, intelligent machine tool assembly lines, and intelligent testing equipment, Equipped with a professional R&D, manufacturing, and sales team, aiming to provide high-quality CNC machine tools and intelligent equipment solutions for the industry.

Relying on strong research and manufacturing capabilities in CNC machine tools, Ever-power not only provides customers with high-quality machine tool equipment, but also integrates and optimizes the industrial chain, providing customers with shared machine tools, intelligent tool cabinets, automation integration solutions, tool health monitoring systems, and other full industry chain equipment and life cycle industrial services. It empowers enterprises in all aspects and achieves industry-leading enterprises with high-quality products and professional services.

Ever-power is committed to providing customers with flexible equipment procurement models such as shared machine tools, machine tool leasing, sales, and rental purchase while connecting the casting, main components, and whole machine assembly industry chain.

1.Thousand machine tools, available for rent in stock 2.Ultra low rent, rent as needed 3.Take action lightly and reduce risks 4.Small investment, large returns 5.Worry free service, lifetime warranty 6.Renting instead of purchasing, flexible model

Ever-power has industry-leading casting production lines such as DISA vertical and horizontal lines, resin sand large, medium and small lines, lost foam production lines, and continuous casting production lines. It can achieve an annual production capacity of 300000 tons of castings and has a complete manufacturing system from casting and forging sheet metal, mechanical processing, heat treatment, packaging and final assembly to warehousing and distribution.

We have advanced lathe flow assembly lines, standard vertical assembly lines, and assembly lines for medium and large equipment. They are also equipped with constant temperature inspection rooms such as coordinate inspection and precision inspection, as well as high-end inspection equipment such as Zeiss high-performance coordinate measuring machines, Will profilometers, and Renishao laser interferometers, providing the industry with high-quality CNC machine tools and automation integration solutions.
