China Supplier Factory Exporter Rexroth Motor De Pistones Radiales

TYPEDisplacement(ml/r)Pressure(Mpa)Torque(N.M)Speed range Max Cont PowerSingle SpeedDouble SpeedPeak pressureCont PressureRate torqueTheoric torqueTMS08-63062731440252371940-17036TMS08-700702351402526541060-17036TMS08-780780390402529491170-17036TMS08-860857429402532411290-17036TMS08-9309344674025353......

Send Inquiry

Product Description

TYPE	Displacement (ml/r)		Pressure (Mpa)		Torque (N.M)		Speed range	Max Cont Power
TYPE	Single Speed	Double Speed	Peak pressure	Cont Pressure	Rate torque	Theoric torque	Speed range	Max Cont Power
TMS08-630	627	314	40	25	2371	94	0-170	36
TMS08-700	702	351	40	25	2654	106	0-170	36
TMS08-780	780	390	40	25	2949	117	0-170	36
TMS08-860	857	429	40	25	3241	129	0-170	36
TMS08-930	934	467	40	25	3532	141	0-170	36
TMS08-1050	1043	522	35	25	3944	157	0-100	36
TMS08-1150	1146	573	35	25	4333	173	0-100	36
TMS08-1250	1248	624	35	25	4719	188	0-90	36
TYPE	Displacement (ml/r)		Pressure (Mpa)		Torque (N.M)		Speed range	Max Cont Power
TYPE	Single Speed	Double Speed	Peak pressure	Cont Pressure	Rate torque	Theoric torque	Speed range	Max Cont Power
TMS11-840	837	419	40	25	3165	126	0-150	44
TMS11-950	943	472	40	25	3566	142	0-150	44
TMS11-1050	1048	524	40	25	3963	158	0-150	44
TMS11-1260	1259	630	40	25	4761	190	0-150	44
TMS11-1270	1263	632	35	25	4776	191	0-150	44
TMS11-1400	1404	702	35	25	5309	212	0-80	44
TMS11-1550	1536	768	35	25	5808	232	0-80	44
TMS11-1700	1687	844	35	25	6379	255	0-80	44
