China Supplier Factory Exporter High Speed Poclain Rexroth Mcr10 Hydraulic Motor

TYPEDisplacement(ml/r)Pressure(Mpa)Torque(N.M)Speed range Max Cont PowerSingle SpeedDouble SpeedPeak pressureCont PressureRate torqueTheoric torqueTMS83-67006679334035252525810100-65123TMS83-83008328416435253149512590-50123TMS83-1000010019501035253789015150-40123TYPEDisplacement(ml/r)Pressure(Mpa)To......

Send Inquiry

Product Description

TYPE	Displacement (ml/r)		Pressure (Mpa)		Torque (N.M)		Speed range	Max Cont Power
TYPE	Single Speed	Double Speed	Peak pressure	Cont Pressure	Rate torque	Theoric torque	Speed range	Max Cont Power
TMS83-6700	6679	3340	35	25	25258	1010	0-65	123
TMS83-8300	8328	4164	35	25	31495	1259	0-50	123
TMS83-10000	10019	5010	35	25	37890	1515	0-40	123
TYPE	Displacement (ml/r)		Pressure (Mpa)		Torque (N.M)		Speed range	Max Cont Power
TYPE	Single Speed	Double Speed	Peak pressure	Cont Pressure	Rate torque	Theoric torque	Speed range	Max Cont Power
TMS125-10000	10000	5000	30	25	37818	1512	0-50	150
TMS125-12500	12500	6250	30	25	47273	1890	0-40	150
TMS125-15000	15000	7500	30	25	56727	2269	0-30	150
