Unique Design Hot Sale Hydraulic Cylinder Parts Tube End Reducer-RED Hydraulic Fitting

The Hydraulic Cylinder Parts Tube End Reducer, also known as the RED Hydraulic Fitting, is a crucial component in hydraulic systems. Designed to connect hydraulic tubes of different sizes, this fitting ensures a secure and leak-free connection, enabling the efficient transfer of hydraulic fluid.Key ......

Send Inquiry

Product Description

Key Features: 1.Precise Tube End Reduction: The RED Hydraulic Fitting is engineered to provide a precise reduction in tube size, allowing for seamless integration of hydraulic tubes with varying diameters. This reduction ensures proper flow dynamics and eliminates the risk of pressure loss or leakage. 2.High-Quality Construction: Crafted from durable and corrosion-resistant materials, our RED Hydraulic Fitting guarantees long-lasting performance even in demanding environments. With excellent tensile strength and resistance to wear, it withstands the rigors of hydraulic applications, ensuring reliability and durability. 3.Easy Installation: The RED Hydraulic Fitting simplifies the installation process, saving valuable time and effort. Its user-friendly design allows for quick and hassle-free connection, reducing downtime and increasing overall productivity. 4.Leak-Free Operation: By utilizing advanced sealing technology, our RED Hydraulic Fitting ensures a tight and leak-free connection. This minimizes fluid loss, prevents contamination, and maintains optimal system performance, enhancing the overall efficiency and effectiveness of your hydraulic setup. 5.Wide Compatibility: Our RED Hydraulic Fitting is compatible with various hydraulic cylinder parts and systems, making it versatile and suitable for a range of applications. It can be used in industrial machinery, agricultural equipment, construction vehicles, and more. At our company, we prioritize quality and customer satisfaction. Our RED Hydraulic Fitting undergoes rigorous testing and inspection, complying with industry standards to provide you with a reliable and high-performing hydraulic solution. With our commitment to excellence and exceptional customer service, we strive to meet your specific needs and exceed your expectations. Choose our Hydraulic Cylinder Parts Tube End Reducer - RED Hydraulic Fitting for a dependable and efficient hydraulic connection. Contact us today to discuss your requirements and experience the superior performance and reliability of our hydraulic fittings.

Installation instructions The nuts of ROKE hydraulic connectors are all silver plated and coated with our patented nano lubricating layer. Through this method, the installation torque can be controlled within a reasonable range. Especially in narrow spaces or suspended operations, installation is very easy. In order to assemble correctly, the assembly instructions should be followed. Improper assembly may cause malfunctions or damage safety.

1. Cut the tube: 1/2 angle tolerance to the tube axis is permissible. Tube cutter is not recommendable.

2. Lightly remove chips and particles from the inside and outside cut edges of tube. Bevel up to 0.2mm × 45 is permissible.
3. For tube bend, the minimum height from the straight pipe end to the bending radius must be at least twice the
height of the nut.
4. Lubricate thread and cone of the fitting body, ring and thread of nut.

Assembly
5. Slip nut and then ring onto the tube end. Ensure that the ring is placed correctly.
6. Screw nut manually onto fitting body until finger tight. Hold the tube against the shoulder in the cone of the fitting body.
7. Mark nut and tube for measuring the prescribed turns of the nut.
8. Tighten the nut 1 1/4 turns. Tube must not turn with tube. Stop edge of the ring limits over-tightening by increasing tightening torque.

Check & Final Assembly
9. Loosen nut and remove ring-mounted tube from fitting. And check if a visivle collar has formed on the pipe in
front of the first cutting edge. If not, tighten slightly more.
10. Insert the pre-assembled tube into the fitting.
While holding fitting body with a wrench, tighten nut approx. 1/4 revolution beyond the point of a clearly perceptible resistance.

EVER-POWER., founded in 2002, is located in Hangzhou City, one of the main manufacturers and exporters of hydraulic cylinders in China. With high-quality products and services, we have won a trustworthy reputation with customers all over the world on the basis of mutual benefit. We firmly believe that reputation and customers are our top priority. Through 16 years of efforts, we have won the trust of customers at home and abroad. At present, Jinwei hydraulic components have been exported to more than 30 countries and regions such as the United States, Canada, Russia, Poland, Germany, Italy, France, Austria, Brazil and Colombia. hydraulic cylinder has reliable quality, stable performance and durability. It is completely interchangeable with the original parts. At the same time, through our own product designers, we can provide customized products and accept OEM orders. We will continue to develop new products and improve our services. If you are interested in any of our products or need any similar products, please contact us or visit our website for more details. We look forward to the opportunity to become your supplier in the near future

Design

Our specialized staff is at your disposalfor technical consultancy relating your project and the best type of materials touse based on your application . We mostly work on drawing , preparing personalized projects according to customer needs

Once the project is defined , we produce our technical drawing by CAD 2D-3D systems and supply it to our customer for approval

Raw Materials

An accurate raw materials and seals selection brings to save costs and allow to produce high quality and powerful cylinders . For that reason , in the materials choice we consider the application field of our cylinder and the environment where it will work Specifically for chromed bars and tubes ,we work only with producers or reliable suppliers

Cylinders Production

We produce about 120.000 cylinders per year and the whole process develops in our factory : cutting of raw materials ,turning and milling machining , components and accessories welding , cylinders mounting and final testing

All the above steps are made with latest generation CNC machines , welding robotized stations and specially made equipment.
