Motor Mini Machine Horizontal Manual Metal Lathe Precision Metal Turning CNC Lathe Machine Horizontal Flat Bed CNC Lathe

CAPACITYSwing over bedmm580Max. turning lengthmm555,1055Max. turning diameter(shaft/disc)mm350Guideway typeRoller guide waySPINDLEChuck sizeInch8Spindle noseISOA2-6Spindle boremm70Spindle speedrpm35-4000Spindle motor powerKw11/15Spindle torqueNm105/140Max bar diametermm51TRAVELX-axis travelmm215Z-ax......

Send Inquiry

Product Description

CAPACITY	Swing over bed	mm	580
		Max. turning length	mm	555,1055
		Max. turning diameter(shaft/disc)	mm	350
		Guideway type		Roller guide way
SPINDLE	Chuck size	Inch	8
		Spindle nose		ISOA2-6
		Spindle bore	mm	70
		Spindle speed	rpm	35-4000
		Spindle motor power	Kw	11/15
		Spindle torque	Nm	105/140
		Max bar diameter	mm	51
TRAVEL	X-axis travel	mm	215
		Z-axis travel	mm	555/1055
		X-axis rapid traverse	m/min	30
		Z-axis rapid traverse	m/min	30
TOOL POST	Turret type and tool number		Hydraulic 12-station turret
		Tool shank size	mm	25x25
		Indexing time(adjacent/farthest)	s	0.31/0.78
TAILSTOCK	Diameter of tailstock quill	mm	50
TAILSTOCK		Tailstock quill travel	mm	140
