MDH 40/60/80 High-speed Torna CNC Vertical Milling Machine 5Axis Milling Machine Horizontal Machining Center

Raydafon Group's MDH 40/60/80 High-speed Torna CNC Vertical Milling Machine is a precision 5-axis machining center ideal for manufacturing professionals, offering unmatched speed, durability, and versatility in horizontal and vertical operations to boost productivity and inspire confidence.
Send Inquiry
Product Description
MDH 40/60/80 High-speed Torna CNC Vertical Milling Machine 5Axis Milling Machine Horizontal Machining Center
MDH 40/60/80 High-speed Torna CNC Vertical Milling Machine 5Axis Milling Machine Horizontal Machining Center
MDH 40/60/80 High-speed Torna CNC Vertical Milling Machine 5Axis Milling Machine Horizontal Machining Center


TABLE
Worktable size
mm
800*800
Workpiece size range
mm
φ1110*1220
Max load of worktable
kg
1300
X/Y/Z axis travel
mm
1050/900/900



SPINDLE
Spindle speed
r/min
8000(6000/12000 Optional)
Spindle taper

NO.50(7:24)
Spindle drive mode

Motorized spindle
Spindle power
kw
18.5
Spindle maximum torque
nm
24
MOVEMENT
X/Y/Z cutting speed
m/min
20
MOVEMENT
X/Y/Z feeding speed
m/min
54




ATC SYSTEM
Tool magazine capacity

40(60/80/120 Optional)
Tool shank type

BT50-45°
Max. tool weight
kg
25
Max. tool diameter (w/o adjacent tools)
mm
 φ115
Max.tool length
mm
500
Time of tool change (T-T)
s
2

ACCURACY
X/Y/Z axis positioning accuracy
mm
0.01
X/Y/Z axis repeatability accuracy
mm
0.006
CONTROL SYSTEM
Controller

GSK/SIEMENS/FANUC
MDH 40/60/80 High-speed Torna CNC Vertical Milling Machine 5Axis Milling Machine Horizontal Machining Center
MDH 40/60/80 High-speed Torna CNC Vertical Milling Machine 5Axis Milling Machine Horizontal Machining Center
MDH 40/60/80 High-speed Torna CNC Vertical Milling Machine 5Axis Milling Machine Horizontal Machining Center
MDH 40/60/80 High-speed Torna CNC Vertical Milling Machine 5Axis Milling Machine Horizontal Machining Center
MDH 40/60/80 High-speed Torna CNC Vertical Milling Machine 5Axis Milling Machine Horizontal Machining Center
MDH 40/60/80 High-speed Torna CNC Vertical Milling Machine 5Axis Milling Machine Horizontal Machining Center
Hot Tags: High-speed CNC Vertical Milling Machine, 5Axis Milling Machine Supplier, Horizontal Machining Center Wholesale
