4x6, 5x7, 5x8, 5x10 Powder Coated Tandem Box Trailer

Chassis Size2400x1500x300mmFinishPowder CoatedWheels185R14C tires with galvanised rimsMudguardsChecker Plate mudguards with StepsLeaf springs5Brake Mechanical brakeJockey wheel10 inch swing upWarranty2 yearsLightse-mark, DOTGVW2000KGAxles50mm round solid axlesMOQ5 PiecesCouplerAU 2000kg brake couple......

Send Inquiry

Product Description

Chassis Size	2400x1500x300mm	Finish	Powder Coated
Wheels	185R14C tires with galvanised rims	Mudguards	Checker Plate mudguards with Steps
Leaf springs	5	Brake	Mechanical brake
Jockey wheel	10 inch swing up	Warranty	2 years
Lights	e-mark, DOT	GVW	2000KG
Axles	50mm round solid axles	MOQ	5 Pieces
Coupler	AU 2000kg brake coupler	Port	Ningbo/Shanghai

Specifications

8x5 Powder Coated Tandem Box Trailer With Tool Box

1.Size:2400x1500x300mm

2.Drawbar: 100*50* 2.75mm 1.8m long from the front gate to the top of A-frame

3.Chassis: 50*30* 2.5mm

4.Flooring: 2.5m checker plate

5.Side panels: 300mm height, 2.5mm checker plate

6.Coupler: AU standard brake coupler with stronger safety chain (other country standard coupler can be choiced)

7.Jack wheel: 10" jack/nose wheel with side/top winds

8.Tyre:14 inch (14C tyre can be choiced)

9.Spring: 5 leaf springs

10.Axle: 50mm round solid with mechanical brake (electric brake can be choiced)

11.Surface treatment: Powder Coated

12.Load capacity:1.7T

13:Min order: 5 sets

14:600mm Cage

Size option	6×4, 7×4, 7×5, 8×5
Axle	50×50mm solid square bar(option: no brake, disc brake, eletronic brake).
Chassis	50×50×2.5mm cross bar(option: 70×50×3mm)
Drawbar	70×50×3mm (option:2 safety chain)
Floor&Mudguard	2.5mm chequer plate
Side panels&gate	300mm hight, 1.5mm flat steel plate
Spring	45×6mm×5leafs eye to eye spring
Jockey wheel	6' jack/nose wheel with side/top winds
Tyre	165/70 R 13, 185/55 R14C 195/70 R15
Light	LED set, 7 pin plug
Surface treatment	Hot-dip galvanizing.

Click Here for more details!

Hangzhou Ever-power Transmission Co, Ltd. Our company is a modem private enterpriswhich integrates R&D, production and sales. Our company has excellent design team andmanagement team. We have absorbed advanced technology of similar products at homeand abroad, designed according to the standards promulgated by the state, and sold theproducts to many countries and regions. The companys main products: flat-plate trailers,heavy-duty trailers, agricultural trailers, water tank trailers, yacht trailers, dump trailers,ATV trailers, cross-country trailers, atmospheric containers and so on; and to undertakethe extemal welding processing business of difficult metal materials; mechanical toolingR&D and production business. The company respects the integrity, win-win businessphilosophy, with a brand-new management model, perfect technology.
