MDH Series Heavy Duty Horizontal Machining Center Cnc Turning Machining Center Cnc Machining Center With Counter Spindles

Raydafon Group's MDH Series Heavy Duty Horizontal Machining Center with Counter Spindles offers precision CNC turning and machining, ideal for manufacturers seeking efficiency and durability. Its advanced technology ensures superior performance and reliability, solving complex production challenges and enhancing productivity in industrial settings. This standout machine delivers unmatched versatility and quality, making it a top choice for professionals.
Send Inquiry
Product Description
MDH Series Heavy Duty Horizontal Machining Center Cnc Turning Machining Center Cnc Machining Center With Counter Spindles
MDH Series Heavy Duty Horizontal Machining Center Cnc Turning Machining Center Cnc Machining Center With Counter Spindles
MDH Series Heavy Duty Horizontal Machining Center Cnc Turning Machining Center Cnc Machining Center With Counter Spindles


TABLE
Worktable size
mm
800*800
Workpiece size range
mm
φ1110*1220
Max load of worktable
kg
1300
X/Y/Z axis travel
mm
1050/900/900



SPINDLE
Spindle speed
r/min
8000(6000/12000 Optional)
Spindle taper

NO.50(7:24)
Spindle drive mode

Motorized spindle
Spindle power
kw
18.5
Spindle maximum torque
nm
24
MOVEMENT
X/Y/Z cutting speed
m/min
20
MOVEMENT
X/Y/Z feeding speed
m/min
54




ATC SYSTEM
Tool magazine capacity

40(60/80/120 Optional)
Tool shank type

BT50-45°
Max. tool weight
kg
25
Max. tool diameter (w/o adjacent tools)
mm
 φ115
Max.tool length
mm
500
Time of tool change (T-T)
s
2

ACCURACY
X/Y/Z axis positioning accuracy
mm
0.01
X/Y/Z axis repeatability accuracy
mm
0.006
CONTROL SYSTEM
Controller

GSK/SIEMENS/FANUC
MDH Series Heavy Duty Horizontal Machining Center Cnc Turning Machining Center Cnc Machining Center With Counter Spindles
MDH Series Heavy Duty Horizontal Machining Center Cnc Turning Machining Center Cnc Machining Center With Counter Spindles
MDH Series Heavy Duty Horizontal Machining Center Cnc Turning Machining Center Cnc Machining Center With Counter Spindles
MDH Series Heavy Duty Horizontal Machining Center Cnc Turning Machining Center Cnc Machining Center With Counter Spindles
Hot Tags: Heavy Duty Horizontal Machining Center, CNC Turning Machining Center, CNC Machining Center with Counter Spindles
