Product Description

Detailed Images

_{Images of Helical shaft mount gear unit gearbox}

Product Description

Helical shaft mount gear unit gearbox

1. Precision High Quality Gearing

Computer designed helical gears, strong alloy materials for high load capacity, ground profile (some intermediate pinions are shaved). Crown tooth profile, in conformance with ISO 1328-1997, 98% efficiency for per stage, smooth quiet operation with several teeth in mesh.

2. Output Hub

*Standard or alternative output hole diameter for choice as follow.

ITEM	Standard output hole diameter	Alternative output hole ø
B5	ø30	ø25/35/40
B13/20	ø30	ø25/35/40
C5	ø40	ø35/45/50
C13/20	ø40	ø35/45/50
D5	ø50	ø45/55/60/65
D13/20	ø50	ø45/55/60/65
E5	ø55	ø50/60/65
E13/20	ø55	ø50/60/65
F5	ø65	ø60/70/75
F13/20	ø65	ø60/70/75
G5	ø75	ø70/80/85
G13/20	ø75	ø70/80/85
H5	ø85	ø80/90/95/100
H13/20	ø85	ø80/90/95/100
J5	ø100	ø90/95/105/110/105120
J13/20	ø100	ø90/95/105/110/105120

3. Strong Alloy Steel Shafts

Strong alloy steel, hardened, ground on journals, gear seatings and extensions, for maximum torsional loads. Generous size shaft keys for shock loading and conform to ISO standards.

4, Back Stops

Alternative parts, anti-run back device, are available on all 13:1 and 20:1. Ratio units and do not recommend for 5:1.

5. Torque Arm Assembly

For easy adjustment of the belt.

Packing & Delivery

Packing Images ofHelical shaft mount gear unit gearbox

Inner Packing: PP bag with carton;
Outer Packing: Wooden case;
Shipment: 20-30 days upon receiving the deposit.
