12 Inch Standard Duty Earth Auger for Post Hole Digger

12 Inch Standard Duty Earth Auger for Post Hole DiggerA 12-inch standard earth auger is a tool for drilling holes on the ground. It usually consists of a spiral drill at the end of a long shaft and is driven by an electric motor or a manual crank. The size of 12 inches refers to the diameter of the ......

Send Inquiry

Product Description

12 Inch Standard Duty Earth Auger for Post Hole Digger

A 12-inch standard earth auger is a tool for drilling holes on the ground. It usually consists of a spiral drill at the end of a long shaft and is driven by an electric motor or a manual crank. The size of 12 inches refers to the diameter of the hole that the earth drill can drill. This type of soil drill is usually used for digging fence pile holes or planting trees and other tasks requiring larger diameter holes. The standard screw bulldozer is designed to be durable, reliable, light and easy to operate. It is a popular choice for two professional uses.

12-inch standard grounding auger specification Soil auger for 12 "diameter standard three-point tractor or sliding steering column excavator Replaceable cutting edge Installed on all gearboxes with 2 "smooth hole output shaft... AgKnx, King Cutter, Speedo, Country Line, Work Saver, Bush Hog, etc 12 "diameter. 48 inches long. Gearbox shaft mounting bolt holes are located at 2 "centers at 90 degrees from each other (standard) High quality and durable unit, very good!! Supported by our outstanding customer support team

12 Inch Standard Duty Earth Auger for Sale

Auger Diameter	Duty & Length	Weight	SKU
6"	Compact - 36"	21	23-033
9"	Compact - 36"	32	23-035
12"	Compact - 36"	43	23-037

6"	Standard - 48"	23	23-032
9"	Standard - 48"	34	23-034
12"	Standard - 48"	49	23-036

6"	Heavy - 48"	31	23-040
9"	Heavy - 48"	42	23-041
12"	Heavy - 48"	60	23-042
18"	Heavy - 48"	99	23-043
24"	Heavy - 48"	125	23-044

For more details, please click here to contact us!

Post Hole Auger for 3 Point Post Hole Diggers

Model	Model 400 Compact	Model 650 Standard Duty	Model 1000 Heavy Duty	Model 1500 Extra Heavy Duty
SKU	24-0361	24-0362	24-0318	24-0337
Category	0 & 1	1	1	1 & 2
Boom Length	56"	60"	72"	72"
Tubing Diameter	2-7/8"	2-7/8"	2-7/8"	3-1/4"
Draw Pin Width	20"	27"	27"	32-1/2"
Drive ine	Series 1	Series 1	Series 4	Series 4
Gearbox	2.9:1	2.9:1	2.9:1	3.18:1
Auger Diameters	6", 9", 12" (3' lengths)	6", 9", 12"	6", 9", 12", 18", 24"	6", 9", 12", 18", 24"
Weight	150 bs	160 bs	200 bs	235 bs
SKU	24-0361	24-0362	24-0318	24-0337
Features	4 Positions	3 Positions	4 Positions	4 Positions

12 inch standard load grounding auger characteristics

Some standard features of the 12-inch standard load auger include: High quality steel structure: the auger is made of high quality steel, light but durable. 12 inches in diameter: The 12 inch earth drill can drill holes up to 12 inches in diameter, which is very suitable for all kinds of work, from fence and bridge deck construction to landscaping and gardening. Ergonomic design: The 12-inch auger handle conforms to the ergonomic design, which is comfortable and easy to use, and minimizes the fatigue and discomfort of users during long-term use. Adjustable depth: The depth of the hole can be easily adjusted, up to 30 inches, so as to achieve higher accuracy and control. Powerful motor: The 12-inch mud auger has a powerful motor that provides the necessary torque and power to dig quickly and efficiently even in the worst soil conditions. Safety features: The 12-inch auger bit is equipped with safety features, such as the safety switch to stop the motor in an emergency to ensure the user's safety at all times. Easy to maintain: The 12-inch earth auger is designed to be easy to maintain, with easy-to-replace parts, and easy to repair and maintain. In general, the 12-inch standard earth auger is a very good tool, suitable for any operation that requires drilling on the ground, providing power, accuracy and ease of use.

12 inch standard load grounding auger characteristics Some standard features of the 12-inch standard load auger include: High quality steel structure: the auger is made of high quality steel, light weight but durable. 12 inches in diameter: The 12 inch soil drill can drill holes up to 12 inches in diameter, which is very suitable for all kinds of work, from fence and bridge deck construction to landscaping and gardening. Ergonomic design: The 12-inch auger handle conforms to the ergonomic design, which is comfortable and easy to use, and minimizes the fatigue and discomfort of users during long-term use. Adjustable depth: The depth of the hole can be easily adjusted, up to 30 inches, so as to achieve higher accuracy and control. Powerful motor: The 12-inch mud auger has a powerful motor, which can provide the necessary torque and power to dig quickly and efficiently even in the worst soil conditions. Safety function: The 12-inch auger bit is equipped with safety functions, such as the safety switch to stop the motor in case of emergency, to ensure the safety of the user. Easy to maintain: 12-inch earth auger is designed to be easy to maintain, parts are easy to replace, and easy to repair and maintain. In general, the 12-inch standard earth auger is a very good tool, suitable for any operation requiring drilling on the ground, providing power, accuracy and ease of use.

We also provide PTO shaft for tractor 3-point post digger

The power take-off (PTO) is an important part of the three-point pillar excavator. It transfers power from the tractor engine to the drilling mechanism of the excavator, so that it can effectively drill holes. When you are looking for the PTO shaft for a 3-point post excavator, you need to ensure that it meets the specifications of the excavator, including: (1) Shaft length: The length of the PTO shaft depends on the distance between the tractor PTO and the excavator driveline. Before purchasing the PTO shaft, make sure to measure the distance carefully to avoid installation problems. (2) Shaft diameter: The shaft diameter of the PTO shaft should match the diameter of the excavator drive train. (3) Shaft end type: check the PTO end type of excavator and tractor, and select a compatible PTO shaft. (4) Safety function: look for PTO shaft with safety function (such as shield) to prevent any accident. In general, it is very important to select a high-quality PTO shaft for your three-point pillar excavator to ensure efficient and safe excavation.

Series	Shortest Length	Extended Length	Tractor End	Implement End	Common Uses	SKU
1	27	34	1-3/8" x 6 QD	1-3/8" x 6 QD	Fertilizer Spreader	27-010
3	40	54	1-3/8" x 6 QD	1-3/8" x 6 QD	Finishing Mower, Tiller	27-011
4	30	40	1-3/8" x 6 QD	1-3/8" Round	Finishing Mower, Tiller	27-012
4	32	42	1-3/8" x 6 QD	1-3/8" Round	Rotary Cutter	27-013
4	36	43	1-3/8" x 6 QD	1-3/8"x6 Clutch	Rotary Cutter, Tiller	27-014
4	37	50	1-3/8" x 6 QD	1-3/8" Round	Rotary Cutters, Pond	27-015
4	42	58	1-3/8" x 6 QD	1-3/8" Round	Post Hole Digger	27-016
4	48	65	1-3/8" x 6 QD	1-3/8" x 6 QD	Post Hole Digger	27-017
4	53	74	1-3/8" x 6 QD	1-1/4" Round	Post Hole Digger	27-018
5	42	57	1-3/8" x 6 QD	1-3/8" Round	Rotary Cutters	27-019
12	48	64	1-3/8" x 6 QD	1-1/4" Round	Heavy Duty Digger	27-020
14	37	49	1-3/8" x 6 QD	1-3/8" Round	Post Hole Digger	27-021
14	56	77	1-3/8" x 6 QD	1-3/8" Round	5' & 6' Pull Cutters	27-022

12-inch standard grounding auger maintenance

Regular maintenance of 12-inch standard soil auger bit is essential to maintain its good condition and extend its service life. Here are some tips for maintaining the earth drill bit: 1. Correct storage: When not in use, store the drill bit in a clean and dry area. Avoid storing it in a humid or humid environment, as it will cause rust and other forms of corrosion. 2. Cleaning: After each use, thoroughly clean the auger bit with a wire brush to remove any dirt or debris. You can also clean them with a rag or sponge. 3. Lubrication: After cleaning, apply a thin layer of lubricant on the auger bit to prevent rust and other forms of corrosion. Be sure to wipe off excess lubricant before using the drill again. 4. Inspection: regularly check whether the earth auger bit has wear signs, such as cracks or debris in the blade. Replace the damaged drill bit as soon as possible to prevent further damage or injury. 5. Sharpening: As time goes by, the blade of the earth spiral drill may become blunt. Grind it with a grindstone or file as required. By following these maintenance tips, you can ensure that your 12-inch standard load auger bit remains in good condition and provides reliable performance in the next few years.

Q: Are you trading company or manufacturer ? A: Our group consists in 3 factories and 2 abroad sales corporations. Q: Do you provide samples ? is it free or extra ? A: Yes, we could offer the sample for free charge but do not pay the cost of freight. Q: How long is your delivery time ? What is your terms of payment ? A: Generally it is 40-45 days. The time may vary depending on the product and the level of customization. For standard products, the payment is: 30% T/T in advance ,balance before shippment. Q: What is the exact MOQ or price for your product ? A: As an OEM company, we can provide and adapt our products to a wide range of needs.Thus, MOQ and price may greatly vary with size, material and further specifications; For instance, costly products or standard products will usually have a lower MOQ. Please contact us with all relevant details to get the most accurate quotation. If you have another question, please feel free to contact us.

FOR MORE DETAIL, PLEASE CONTACT US.
