unbraked hub
load up to 2000kg
6 holes PCD 139.7
trailer half axle kit
complete with bearing, race ,seal, etc
trailer half axle hub kit square unbraked
Specs:
Hub Material: HT250 / QT450
Surface Treatment: galvanized white / painted black
Bolt: 4, 5, 6 stud
PCD: 4 , 4.25 , 4.5 , 4.75 , 5.5 inch
complete with axle, spindle, mech/elec/hydr brake disc, drum, shoe&liniing, oil seal, pin, lug nut etc
2200lbs 3500lbs 7000lbs square/round solid axle stub complete with wheel hub
| Model | Dim(X) | PCD(Y) | Bolt | Bearing |
| AT01700102 | 192.4 | 139.7 | 6*1/2" | L67048/LM11949 |
| AT01700103 | 192.4 | 139.7 | 6*1/2" | L68149/LM12749 |
| AT01700104 | 138.8 | 108 | 5*7/16" | L67048/LM11949 |
| AT01700105 | 152.4 | 108 | 5*7/16" | L67048/LM11949 |
| AT01700106 | 152.4 | 120.65 | 5*7/16" | L67048/LM11949 |
| AT01700107 | 152.4 | 114.3 | 5*1/2" | L67048/LM11949 |
| AT01700108 | 152.4 | 108 | 5*7/16" | L68149/LM12749 |
| AT01700109 | 152.4 | 120.65 | 5*7/16" | L68149/LM12749 |
| AT01700110 | 152.4 | 114.3 | 5*1/2" | L68149/LM12749 |
| AT01700111 | 138.8 | 101.6 | 4*7/16" | L67048/LM11949 |
| AT01700112 | 183.5 | 139.7 | 6*1/2" | 25580/15123 |
| AT01700113 | 152.4 | X | 5*1/2" | L68149/LM12749 |
| Note: complete with bearing, race ,seal, lug nut, pin etc | ||||
| 101.6mm=4inch | 108mm=4.25inch | 114.3mm=4.5inch | ||
| 120.65mm=4.75inch | 139.7mm=5.5inch | |||
Unbraked Half Axle assembly
Electric Braked Half Axle assembly, 10 inch brake plate, for 2000kg trailers
Boat Trailers, Box Trailers, Car Trailers, Caravan, Mobile Home Axle Parts, No brake HUB Stud Assembly
