F Series Parallel Shaft Helical Gearbox

product description:
1, F series reducer with international technical requirements, with high technological content.
2, save space, reliable and durable, with high overload capacity, power up to 90KW.
3, F series parallel shaft helical gear reducer low energy consumption, superior performance, efficiency up to 95%.
4, parallel shaft helical gear reducer vibration, low noise, high energy efficiency, the selection of high-quality steel, steel castings, gear surface after high-frequency heat treatment.
5, after precision machining, to ensure the parallelism and positioning accuracy of the axis, all of which constitute a gear drive assembly reducer equipped with various types of motor, the formation of a mechatronic, fully guarantee the use of gear motor product quality characteristics.
Features:
1, parallel output, compact structure, transmission torque, stable work, low noise, long life.
2, Installation: base installation, hollow shaft installation, flange installation, torque arm installation, small flange installation.
3, the basic two-level input and output rotation in the same direction, the three opposite; F / R combination of consultation.
4, the output mode: hollow shaft output or solid shaft output.
5, the average efficiency: two 96 percent, three 94percent, F series / R series combination of the average efficiency of 85percent.
Technical Parameters:

structure type:
F-shaft extension, foot-mounted FF-shaft extension, flange connection
S-axis input FA-shaft mounted coupling



All gear materials used 20CrMnTi, carburized, tooth surface hardness of 58-62HRC, after grinding teeth up to 6 accuracy, to ensure product reliability and low noise. Reducer reducer from 0.09KW-160KW, the output torque up to 20N.M-15000N.M, speed ratio from (with 4-pole motor) 4.3-273, can be divided into two-stage transmission (transmission efficiency up to 96percent), Three-stage transmission (transmission efficiency of up to 94percent); with 6-pole or 8-pole motor can get lower output speed; For lower output speed can be used in combination of two-stage reducer, you can get a lower Output speed (more than ten thousand speed ratio). Above, such as the input coupled with continuous variable speed transmission can achieve more requirements. There are two types of vertical and horizontal installation, the output shaft form solid mandrel, hollow shaft (or non-standard production), can be installed in different directions to use, can be used. In addition can be equipped with different types of motor (ordinary motor, single-phase motor, explosion-proof motor, variable frequency motor, brake motor, etc.). F series parallel shaft helical gear reducer is widely used in food grain machinery, printing and packaging machinery, three-dimensional garage equipment, environmental protection machinery, transportation equipment, chemical equipment, metallurgical mining equipment, steel power equipment, etc.

KAF-shaft, flange mounting
